DAXLIFTER DX4000 series fixed electric hydraulic scissor lift table delivers stable vertical material transportation with standard 4000kg load capacity, offering diversified specifications including platform dimensions ranging from 1700×1200mm up to 2200×1800mm, minimum platform height between 240mm and 350mm and maximum lifting height covering 1050mm,1300mm and 1400mm for different working demands. This stationary scissor lifting platform is designed for permanent installation inside factory workshops, logistics warehouses and production assembly lines to realize automatic height adjustment for goods loading, workpiece assembly and pallet transfer. Constructed with reinforced manganese steel scissor arms and integrated hydraulic power unit, our fixed lift table features anti-explosion hydraulic valves, overload protection and safety limit switches to guarantee secure continuous operation under heavy load conditions.
Our DX4000 model lineup covers 8 standard options to match various site layouts: DX4001, DX4002, DX4003, DX4004, DX4005, DX4006, DX4007, DX4008. Customers can select proper platform length, width, collapsed height and lifting range according to pit size and cargo dimension. The whole structure adopts high-strength welded technology, wear-resistant platform surface and warning safety strips on scissor arms to avoid accidental collision. This pit mount scissor lift works perfectly with forklifts, assembly conveyor systems and packaging production lines, greatly lowering manual labor intensity and improving material handling efficiency.
Industrial production line workpiece lifting, warehouse pallet loading & unloading, logistics distribution center cargo height adjustment, factory packaging workshop, machinery assembly workshop, food processing factory, auto parts manufacturing and other indoor fixed material handling occasions.
| Model | Load capacity | Platform size (L*W) | Min platform height | Platform height | Weight |
|---|---|---|---|---|---|
| 4000Kg Capacity | |||||
| DX4001 | 4000kg | 1700×1200mm | 240mm | 1050mm | 375kg |
| DX4002 | 4000kg | 2000×1200mm | 240mm | 1050mm | 405kg |
| DX4003 | 4000kg | 2000×1000mm | 300mm | 1400mm | 470kg |
| DX4004 | 4000kg | 2000×1200mm | 300mm | 1400mm | 490kg |
| DX4005 | 4000kg | 2200×1000mm | 300mm | 1400mm | 480kg |
| DX4006 | 4000kg | 2200×1200mm | 300mm | 1400mm | 505kg |
| DX4007 | 4000kg | 1700×1500mm | 350mm | 1300mm | 570kg |
| DX4008 | 4000kg | 2200×1800mm | 350mm | 1300mm | 655kg |
If you need customized specifications, special anti-slip platform, remote control system or explosion-proof configuration, welcome to send your detailed requirements to us for professional solution.
