Looking for reliable compact seated electric counterbalance forklift for narrow aisle warehouse stacking? Our DAXLIFTER CPD series 3-wheel electric forklift covers 3 load capacity variants: SC10 rated load 1000kg, SC13 rated load 1300kg, SC15 rated load 1500kg, standard load center 400mm, fully electric drive unit with seated operation type, two config options including standard type and EPS electric power steering model SCZ10/SCZ13/SCZ15. This industrial electric stacker adopts 2.0KW drive motor & 2.0KW lift motor, matched with 300Ah/24V storage battery, mast lifting height optional 2500mm or 3200mm, max working height reaches 3275mm and 3975mm separately, free lift height fixed at 140mm. Overall length of SC10 model is 2390mm, SC13 & SC15 overall length 2540mm, overall width 800mm / front wheel outer width 1004mm, overhead guard height 1885mm, minimum ground clearance 80mm, turning radius 1440mm for 1ton forklift, 1590mm for 1.3ton & 1.5ton model, minimum stacking aisle width 2765mm (SC10) / 2920mm (SC13/SC15) suitable for 1200*800 pallet transport. Fork dimension is standard 800×100×35mm with adjustable max fork width 215-650mm, mast obliquity α/β 1°/7°, net weight without battery ranges from 1465kg to 1650kg, standard battery weight 275kg. Equipped with original USA CURTIS electric control system, AC maintenance-free traction motor, optional EPS electric power steering system for light operation, high-strength vehicle frame & mast structure to extend service life, widely used in indoor factory, storage warehouse, supermarket logistics, port small cargo handling, cross-border export to global markets including Europe, America, Australia, Southeast Asia, Middle East, Africa.
This seated electric stacker features ultra-small turning radius 1440mm/1590mm, much smaller than 4-wheel electric forklift, minimum stacking aisle width only 2765-2920mm, perfectly solve space limit problems for small warehouse, cold storage, retail distribution center, supermarket back storage, small factory workshop in USA, Germany, UK, Malaysia, Vietnam, Thailand, Saudi Arabia, UAE, Australia.
Original imported CURTIS electric controller ensures stable running under heavy load, low failure rate, easy maintenance for overseas buyers, spare parts supply supported for all export countries, meets EU CE, US OSHA industrial vehicle safety standard.
Thickened mast and vehicle body structure, anti-wear metal parts, suitable for daily high-frequency cargo stacking work in manufacturing plant, logistics park, e-commerce warehouse, wholesale distribution warehouse, reduce machine replacement cost for global business owners.
2.0KW AC traveling motor without carbon brush replacement, strong torque output, stable climbing capacity under full 1000kg/1300kg/1500kg load, no frequent maintenance downtime, save labor cost for warehouse operators in all countries.
Upgrade EPS power steering version greatly reduce steering resistance, light & nimble operation for long-hour shift work, suitable for female operators, large-volume logistics companies with all-day stacking tasks; standard mechanical steering model SC10/SC13/SC15 for cost-effective budget buyers.
| Classification | Item | Symbol | Unit | CPD SC10 / SCZ10 | CPD SC13 / SCZ13 | CPD SC15 / SCZ15 |
|---|---|---|---|---|---|---|
| Identification Character | Product Model | - | - | SC10(Standard) / SCZ10(EPS) | SC13(Standard) / SCZ13(EPS) | SC15(Standard) / SCZ15(EPS) |
| Drive Unit | - | - | Electric | |||
| Operation Type | - | - | Seated | |||
| Rated Load Capacity | Q | kg | 1000 | 1300 | 1500 | |
| Load Center | C | mm | 400 | |||
| Dimension Parameter | ||||||
| Dimension | Overall Length | L | mm | 2390 | 2540 | 2540 |
| Overall Width / Front Wheels Outer Width | b | mm | 800 / 1004 | |||
| Overall Height (Closed mast) | - | mm | 1870 / 2220 | 1870 / 2220 | 1870 / 2220 | |
| Overhead Guard Height | H2 | mm | 1885 | |||
| Lift Height | H | mm | 2500 / 3200 | 2500 / 3200 | 2500 / 3200 | |
| Max Working Height | H1 | mm | 3275 / 3975 | 3275 / 3975 | 3275 / 3975 | |
| Free Lift Height | H3 | mm | 140 | |||
| Fork Dimensions | L1×b2×m | mm | 800×100×35 | 800×100×35 | 800×100×35 | |
| Maximum Fork Width | b1 | mm | 215~650 | |||
| Minimum Ground Clearance | m1 | mm | 80 | |||
| Min. Aisle Width for Stacking (1200×800 pallet) | Ast | mm | 2765 | 2920 | 2920 | |
| Mast Obliquity | α/β | ° | 1 / 7 | |||
| Turning Radius | Wa | mm | 1440 | 1590 | 1590 | |
| Electric Motor & Battery | ||||||
| Electric Motor | Drive Motor Power | - | KW | 2.0 | ||
| Lift Motor Power | - | KW | 2.0 | |||
| Battery Spec. | - | Ah/V | 300 / 24 | |||
| Machine Weight | ||||||
| Weight | Net Weight (Without Battery) | - | kg | 1465 / 1490 | 1500 / 1525 | 1625 / 1650 |
| Battery Weight | - | kg | 275 | |||
This DAXLIFTER 3-wheel seated electric counterbalance forklift is widely applied for indoor material handling across all global industrial sectors:
Matching Pallet Type: Standard 1200×800 wooden pallet, plastic pallet, metal pallet, light duty cargo pallet, small turnover box stacking.
